Ubiquiti UAP-AC-M WiFi 5 Access Point (AC)
Ubiquiti UAP-AC-M UniFi Mesh is an AC1200 Dual-Band WiFi 5 PoE Access Point that offers powerful plug and play, self healing mesh technology for large WiFi deployments looking to maximize WiFi coverage and reliability.
£114.42 inc.VAT / £95.35 exc.VAT
Ubiquiti UAP-AC-M UniFi Mesh Outdoor WiFi 5 PoE Access Point (1.2Gbps AC)
Ubiquiti UAP-AC-M WiFi 5 Access Point (AC)
The Ubiquiti UAP-AC-M WiFi 5 Access Point (AC) that offers powerful plug and play, self healing mesh technology for large WiFi deployments looking to maximize WiFi coverage and reliability. This Ubiquiti UAP-AC-M UniFi Mesh is designed to withstand the elements, making it ideal for outdoor deployments and comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service.
Key Features
- High-performance wide-area WiFi with UniFi Mesh technology.
- 802.11ac breakthrough WiFi speeds up to 900Mbps 5GHz Band.
- Powered through 802.3af or 24V Passive Power over Ethernet (PoE).
- Easy to provide coverage in hard to wire areas with multi-hop.
- Works with the UniFi controller for easy on-going management.
- Unifi allows wireless connectivity between APs for extended range.
- Guest portal/hotspot support with multiple adjustment interface.
- Scalable. Start with one and expand to thousands of UniFi devices.
- Can be used indoors or outdoors.
Specifications
Hardware
- Dimensions- 353 x 46 x 34.4 mm (13.9 x 1.81 x 1.35″)
- Weight- 152g with Antennas
- Networking Interface- 1x 10/100/1000 Ethernet Port
- Buttons- Reset
- Power Method- 24V Passive PoE (Pairs 4, 5+; 7, 8 Return); 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return) (Supported Voltage Range: 44 to 57VDC)
- 802.3af PoE
- Power Supply 24V, 0.5A Gigabit PoE Adapter (Included)
- Maximum Power Consumption- 8.5W
- Maximum TX Power- 2.4 GHz; 20 dBm 5 GHz; 20 dBm
- Antennas- 2x External Dual-Band Omni Antennas. 2.4 GHz; 3 dBi 5 GHz; 4 dBi
- WiFi Standards- 802.11 a/b/g/n/ac
- Wireless Security- WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
- BSSID- Up to Four per Radio
- Mounting- Wall/Pole/Fast-Mount (Kits Included)
- Operating Temperature- -30 to 70C
- Operating Humidity- 5 to 95% non-condensing
- Certifications- CE, FCC, IC
Advanced Traffic Management:-
- VLAN- 802.1Q
- Advanced QoS- Per-User Rate Limiting
- Guest Traffic Isolation- Supported
- WMM- Voice, Video, Best Effort, and Background
- Concurrent Clients- 200+
Supported Data Rates (Mbps):-
- 802.11ac- 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2/3, VHT 20/40/80)
- 802.11n- 6.5 Mbps to 300 Mbps (MCS0 – MCS23, HT 20/40)
- 802.11a- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11g- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11b- 1, 2, 5.5, 11 Mbps
Standard Warranty: 1-Years
| Weight | 0.152 kg |
|---|---|
| Dimensions | 35.3 × 4.6 × 3.44 cm |
