Ubiquiti UBB-XG UniFi Outdoor 60GHz WiFi Point to Point Link
Ubiquiti UBB-XG UniFi Outdoor 60GHz WiFi 5 Point-To-Point PtP Link Kit is a 60 GHz, PtP link that creates short-range, high-throughput connections while also sustaining blazing-fast speed across distances up to 500 m.
Some 60GHz products require an Ofcom EHF licence.
£1,120.61 inc.VAT / £933.84 exc.VAT
Ubiquiti UBB-XG UniFi Outdoor 60GHz WiFi 5 Point-To-Point PtP Link Kit (6.8Gbps)
Ubiquiti UBB-XG UniFi Outdoor 60GHz WiFi Point to Point Link
The Ubiquiti UBB-XG UniFi Outdoor 60GHz WiFi 5 Point-To-Point PtP Link Kit is a 60 GHz, PtP link that creates short-range, high-throughput connections while also sustaining blazing-fast speed across distances up to 500 m. Designed for plug-and-play simplicity, the UBB XG’s bridging units come pre-paired out of the box and both feature calibration LEDs that help you easily adjust their angle and position to optimize signal transmission. Seamlessly integrated with the UniFi Network application, the UBB XG can be set up in minutes and managed from a central, intuitive interface, making network bridging easier than ever!
Key Features
- One (1) 1GbE RJ45 port.
- One (1) 10Gbps SFP+ port.
- 5 GHz radio for backup redundancy.
- Operational range of up to 500 metres.
- Pre-paired bridging units.
- Calibration LEDs ensure an easy alignment process.
- Compact design.
- IPX6-rated, weatherproof casing.
- Terragraph-certified.
- Managed with the UniFi Network application (version 6.3 or higher).
Specifications
Mechanical
Dimensions
- Ø 191.8 x 59 mm (Ø 7.6 x 2.32 in.)
Weight
- Without mount: 1.7 kg (3.8 lb.)
- With mount: 2.9 kg (6.3 lb.)
Enclosure materials
- Aluminium alloy, UV resistant polycarbonate
Mount material
- Stainless steel (SUS304)
Mounting
- Pole compatibility: Ø25.4-63.5 mm (Ø1-2.5 in.)
Weatherproofing
- IPX6
Hardware
Networking interface
- (1) GbE RJ45 port
- (1) 1/10G SFP+ port
Management interface
- Ethernet
- Bluetooth
Power method
- PoE++
- Passive PoE:
- 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
- 2-pairs (4, 5+; 7, 8-)
Power supply
- UniFi PoE switch
- 48V, 0.65A Gigabit PoE adapter (included)
Supported voltage range
- 48V DC ± 10%
Max. power consumption
- 31.2W
Max. TX power
- 2.4 GHz: –
- 5 GHz: 23 dBm
- 60 GHz: 16 dBm
Throughput rate
- 2.4 GHz: –
- 5 GHz: 866.6 Mbps
- 60 GHz: 6 Gbps
Antenna gain
- 2.4 GHz: –
- 5 GHz: 14 dBi
- 60 GHz: 21 dBi
Maximum range
- 500 m (1,640 ft.)
LEDs
- R/G/B
Button
- Factory-reset
Mounting
- 60G precision alignment pole mount (Included)
Operating temperature
- -40°C to 55°C (-40°F to 131°F)
- Operating humidity
- 5% to 95% noncondensing
Certifications
- FCC, IC, CE, terragraph
Software
WiFi standards
- 802.11ac/ad/ay
Wireless security
- WPA2 AES (Always on)
Operating modes
- PtP
VLAN
- Management VLAN only
RF
Operating Frequency
- 57 to 66 GHz
- Note: Depends on regulatory region.
Channel bandwidth
- 2,160/4,320 MHz (Channel Bonding Enabled)
Operating channels
- 58,320/59,400/60,480/61,560/62,640/63,720/64,800 MHz
- Note: Depends on regulatory region.
Back-Up RF
Operating frequency
- US/CA
- U-NII-1 5150 – 5250 MHz
- U-NII-2A: 5,250 – 5,350 MHz
- U-NII-2C: 5,470 – 5,725 MHz
- U-NII-3: 5,725 – 5,850 MHz
- Worldwide
- 5150 – 5725 MHz
- Note: Depends on regulatory region.
- 5150 – 5725 MHz
Channel bandwidth
- 20/40/80 MHz
Package
Package contents
- 2 x Ubiquiti UBB-XG
- 2 x Power cables
- 2 x Precision mounts
- 2 x Pole brackets
- 2 x Screw kits
- 2 x PoE adapters
- 2 x Power cords
Standard Warranty: 1-Years
| Weight | 2.9 kg |
|---|---|
| Dimensions | 19.18 × 5.9 cm |
